S/N

Item

Parameters

1

Center Frequency(F0)

1085MHz

2

Pass Band Frequency

1075 ~ 1095MHz

3

Pass Band Insertion Loss

≤1.0dB

4

Pass Band Return Loss

≥18dB

5

Stop Band Rejection

≥50dB @ DC ~ 950MHz

≥50dB @ 1220 ~ 3000MHz

6

Impedance

50 Ohms

7

Power

10W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black

10

Temperature Range

-20℃ ~ +60℃

11

Material

Housing: 6061 Aluminum alloy

Cover: LY12 Aluminum alloy

Tuning screw: H62 Copper alloy

Resonant column: H59 Copper alloy

Connectors: H59 Copper, Plated ternary alloy

Other screw: Stainless Steel

12

Dimensions

95*35*24mm

13

Net weight

0.12KG
