S/N

Item

Parameters

RX

TX

1

Center Frequency(F0)

2535MHz

2655MHz

2

Pass Band Frequency

2500 ~ 2570MHz

2620 ~ 2690MHz

3

Pass Band Insertion Loss

≤1.0dB

≤1.0dB

4

Pass Band Ripple

≤0.5dB

≤0.5dB

5

Pass Band Return Loss

≥18dB

≥18dB

6

Stop Band Attenuation

≥70dB @ 2620 ~ 2690MHz

≥70dB @ 2500 ~ 2570MHz

7

Impedance

50 Ohms

8

Power

30W Max.

9

Connectors

N-Female

10

Surface Finish

Painted Black

11

Port Sign

Port 1: ANT ; Port 2: RX ; Port 3: TX

12

Temperature Range

-40℃ ~ +70℃
