S/N

Item

Parameters

RX

TX

1

Center Frequency(F0)

2480MHz

2500MHz

2

Pass Band Frequency

2475 ~ 2485MHz

2499 ~ 2501MHz

3

Pass Band Insertion Loss

≤2.0dB

≤2.0dB

4

VSWR

≤1.5:1

≤1.5:1

5

Isolation

≥60dB @ 2475 ~ 2485MHz , 2499 ~ 2501MHz

6

Stop Band Rejection

≥65dB @ DC ~ 2350MHz , 2620 ~ 4000MHz

7

Impedance

50 Ohms

8

Power

300W Max.@公共端

9

Connectors

N-Female

10

Temperature Range

-20℃ ~ +60℃
