Serial

Parameters

1

Center Frequency (F0)

1615MHz

2

Pass Band Bandwidth

10MHz (1610～1620MHz)

3

Pass Band Insertion Loss

≤2.0dB

4

Pass Band VSWR

≤1.3:1

5

Stop Band Attenuation

≥20dB @ F0±10MHz

(1605MHz、1625MHz)

≥30dB @ F0±20MHz

(DC～1595MHz、1635～3000MHz)

6

Impedance

50 ohms

7

Power Handling

≤10W

8

Connectors

SMA-Female

9

Surface Finish

Black Paint

10

Net Weight

TBD

11

Configuration

As Below (Size Unit: mm)
